Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater

Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater
Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater

큰 이미지 :  Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater

제품 상세 정보:
원래 장소: 중국
브랜드 이름: GME
인증: ISO/CE/UL/CSA
결제 및 배송 조건:
최소 주문 수량: 50개
가격: USD 1-100 FOB Shanghai/pc
포장 세부 사항: 박스 또는 나무로 된 통
배달 시간: 7-15 근무일
지불 조건: 인수 인도, D/P (지급도 조건), 전신환, 웨스턴 유니온, 머니그램, L/C (신용장)
공급 능력: 10000pcs/월
상세 제품 설명
리드선: 실리콘, 유리질섬유 스헬스 재료: SS304, SS321, SS316
색상: 비아크와 백색 와트수 허용한도: +5%, -10%
애플리케이션: 기름, 물 또는 다른 유동적 등 전원: 전기 같은
전압: 12-480V 치수(l*w*h): 맞춤형
유형: 공기 가열기, 카트리지 히터 격리: 산화마그네숨 분말
강조하다:

Stainless steel cartridge heater

,

Industrial electric rod heater

,

Resistance heating element cartridge

Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater



Description:


Cartridge heater is made of single head, electric heating tube to tube is to protect the shell (including not only the head of the stainless steel electric heating tube, copper pipe, all kinds of imported steel), along the central axis uniform spiral tube of high quality electric thermal bonding wire, nickel chromium wire, iron chromium alloy fever), and then fill the gap part closely with good heat resistance, thermal conductivity and the crystallization of the insulation of magnesia powder, with silicone seal on both ends of the pipe, in the other process.






Specification:



A.Nickel chromium resistance wire ensures even, efficient distribution of heat to sheath.


B.Magnesium oxide insulation of specific grain and purity results in high dielectric strength and faster heat-up.



C.According to different use requirements,choose the grade of heating wire,magnesium rod and
pipe.

D.Do not pull or bend the wire forciby.

E.The vicinty of the wire should be controlled below 220℃.


Product Name
right angle cartridge heater
Material
stainless steel
Color
nickel white
Standard
CE/ISO
Grade
SUS201, SUS304, SUS316,
Power
electric
Voltage

customized

Used
air heater,water heater



Application:



* 3D Printers
* Hot runner systems - Heating of manifolds
* Laboratories - Heating of analytical equipment
* PCB Equipment, Smokeless barbecue furnace
* Glass Bending Machine, Hole Punched
* Injection Molding



Stainless Steel Industrial Electric Rod Resistance Heating Element Cartridge Heater 0
